A8 heating series air curtain
Pandawind air curtains Application: sports center, big supermarket, subways, large shop, department store, factory…
For installation heights to 3m (environmental separation) and 2.5m (insect control)
| Weight | 14-20.5 kg |
|---|---|
| Dimensions | 90-150 × 18 × 21.5 cm |
| Air Speed | 8m/s |
| Frequency | 50Hz, 60Hz |
| Voltages | 220V, 380V |
A8 heating series air curtain product video
see more details on the video
main points in this video
- Check A8 heating series air curtains at different angles
- What is the advance of A8 heating series air curtains?
- Why you should choose this series of air curtains?
- When do we use A8 heating series air curtains?
- Where is the installation of A8 heating series air curtains?
- How to installation A8 heating series of air curtains?
A8 heating series air curtain data sheets
| Model | Vol/ (V) | Fre(Hz) | Motor input power (W) | Heating Power(KW) | Temp. Rise (K) | Air Velocity (M/S) | Air Volume (M3/H) | N.W (KG) | G.W (KG) | Unit Size (MM) | Packing Size (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RM-1209-3D06/Y-A8 | 220-380 | 50 | 140 | 6 | 25 | 8 | 800 | 14 | 15 | 900X180X215 | 940X229X270 |
| RM-1212-3D08/Y-A8 | 220-380 | 50 | 200 | 8 | 25 | 8 | 1000 | 17.5 | 19.1 | 1210X180X215 | 1250X229X270 |
| RM-1215-3D10/Y-A8 | 220-380 | 50 | 280 | 10 | 25 | 8 | 1500 | 20.5 | 22.5 | 1460X180X215 | 1500X229X270 |
why choose pandaWind A8 heating series air curtain
The Most Important Thing Is To Choose The Correct And Effective Air Curtains. Why?
According to the NSF & AMCA standard, air curtains for customer entry shall have a minimum 8 inches (200mm) air stream depth and an air velocity of at least 600fpm (3.05m/s). the measurement point shall be at a distance of 3 ft (0.9m) above the floor.
For our A8 heating series air curtains, the max air velocity can reach 3.5m/s, so, our air curtains can definitely meet NSF & AMCA standards!
features
- Super Easy To Install, Operate, Clean, And Maintain
- Cross-flow model with PTC heating
- Remote Control And Door Switch Are Optional
- Pure Copper And Two-Speed Motor
- High-Quality Aluminum Cross-Flow Fan With Low Noise Operation
- Strong Air Flow & Air Speed By Perfect Structure Design
- Ultra-Slim Design Suitable Most Commercial Building
benefits
- Invisible Door = Customers-friendly
- Warm air when the customer enters the door
- Insect & Pests Stopper
- Temperature Stability = Reduce Energy Loss
- indoor environment keeper = improve customer satisfy
- Perfect ROI
- HVACR & Compressor-Friendly
